Single Screw Extruder for cable production





TYPE &PARAMETERS

SJB 45－

SJB 65－

SJB 90－

SJB 120－

SJB 150－

SJW 150－

2528

252830

252830

252830

2528

6

SCREW DIAMETER

45mm

65mm

90mm

120mm

150mm

160

EFFECTIVE LENGTH

25D   28D

25D 28D 30D

25D 28D 30D

25D 28D 30D

25D 28D

6D

MOTOR POWER

7.5Kw7.5Kw

30Kw40Kw40Kw

75Kw90Kw90Kw

80Kw110Kw110Kw

140Kw 200Kw

50Kw

MOTORFORM

D.C.

A.C.

D.C.

A.C.

D.C.

A.C.

D.C.

A.C.

D.C.

A.C.

D.C.

A.C.

SCREW SPEED(r/min)

120140

120110120

110110100

8490100

7075

50

NUMBER OF BARREL

HEATING ZONES

3/34/4

4/44/45/5

5/55/56/6

5/56/67/7

8/89/9

1/1

COOLING MEDIA

AIR

AIR

AIR

AIR

AIR

AIR

HEATING CAPACITY

8Kw9 Kw

16Kw 16Kw 19Kw

28Kw 28Kw 32Kw

52Kw 52Kw 60Kw

70Kw 72Kw

9Kw

CYLINDER MATERIAL

BIMETAL

BIMETAL

BIMETAL

BIMETAL

BIMETAL

BIMETAL

INTAKE EXECUTION

SMOOTH GROOVED

SMOOTH

GROOVED

SMOOTH GROOVED

SMOOTH GROOVED

SMOOTH GROOVED

GROOVED

SCREW MATERIAL

BIMETAL /

NITRIDABLE

BIMETAL /

NITRIDABLE

BIMETAL /

NITRIDABLE

BIMETAL /

NITRIDABLE

BIMETAL /

NITRIDABLE

NITRIDABLE

CENTER ALTITUDE

1000mm

1000mm

1000mm

1000mm

1100mm

1100mm

MAX.OUTPUT(kg/hr)

HDPE

70

150

350

450

650



SPVC

48

120

300

300

500

1000

PS



100

360

500







※ There are three A.D. adjustable speed ways could be chosen.

※ All the design data above is for a general extruder only, any more special inquiry, such asspecial raw material to be run, ahigher output want to got,alower energy consumption want to got...,and so on,welcome to discuss with us.

Chief Engineer Office / Shanghai Omega Machinery Co., Ltd

Extrusion professional
We have several advantages over our competitors:
  • Strong designing strength
    We design and manufacture the screws, barrels, and extruders according to customer requirements.
  • Rich experience
    We have been in the extrusion industry for decades, and our products are used by prominent companies such as Foxconn.
  • Advanced material technologies
    Our PM-HIP processing technology increases the material density and reduces casting defects. The new design of an aluminum alloy clad layer on SiC ceramic allows the extruder to work, even in harsh conditions.
Whatever You Need
We are looking forward to your reply. If you need more information about us or customization information, please do not hesitate to contact us.
