OMEGA 25-3D Filament Extruder Machine

1. Main technical parameters Of OMEGA 25-3D Filament Extruder Machine:

1) Model: OMEGA 25-3D

2) ScrewL/D: 20

3) Screw working length: 500mm

4) Screw rotating speed(Max): 50rpm

5) Output (kg, Max): 1~2kg/hr (For normal 3D polymer materials, the output varies with different materials and the different process formula)

6) Power of main motor: 1.1kW with AC frequency conversion motor

7) Speed ratio ofreducer: 30

8) Maximum bearing torque on the reducer output shaft: 210Nm

9) Installed capacity: 7.2kVA, Smooth-running power consumption 85%

10) Temperature control zone on barrel: 3 Zones, each zone is equipped with a ceramic heater

11) Height of screw center: 900mm(Can be adjusted according to user needs)

12) Weight of extruder:~400kg

13) Size of extruder: L2200XW650XH1300



2. Design and configuration characteristic for OMEGA 25-3D Filament Extruder Machine:

1) Targeted design of the core components for the extruder to achieve low shear on material but still have high mixing and plasticizing capacity, can ensure that the extruder has an excellent specific flow;

2) The length to diameter ratio of 20 to be chosen, because it is suitable for both filament and granulation, for an extruder that needs higher plasticizing capacity and a higher back pressure which can be established in front of the head, meanwhile the material extrusion pressure is more uniform under the periodic rotation push by the screw;

3) The main motor adopts the German Siemens Bader brand and ABB governor to achieve accurate and reliable frequency conversion mode to accurately control the size of the filament requirements. The main motor adopts frequency conversion control instead of DC control, which is also to consider the requirements of filament extrusion.

4) Equipped with high-end Japanese OMRON brand temperature control meter to achieve accurate control of material temperature;

5) Most of the electrical parts are using the German SCHNEIDER brand to ensure the high reliability and high stability in the extruder operation process.



CHIEF ENGINEER OFFICE / SHANGHAI OMEGA MACHINERY CO., LTD

We have several advantages over our competitors:

• Strong designing strength
  We design and manufacture the screws, barrels, and extruders according to customer requirements.
• Rich experience
  We have been in the extrusion industry for decades, and our products are used by prominent companies such as Foxconn.
• Advanced material technologies
  Our PM-HIP processing technology increases the material density and reduces casting defects. The new design of an aluminum alloy clad layer on SiC ceramic allows the extruder to work, even in harsh conditions.

We are looking forward to your reply. If you need more information about us or customization information, please do not hesitate to contact us.
